SINEWAVE UPS:
We are a reputed dealer of a quality range of Sine wave Home UPS that is available with a wide input voltage range. These UPS find applications in electronic and electric industry and are well known for their easy installation and low maintenance.
Our range of UPS is available in various models that are as follows :
* 600 VA 12 V DC
* 800 VA 12 V DC
* 1400 VA 24 V DC
Features :
* DSP based design with absolute and stable Sine wave output voltage and frequency
* State of art MOSFET based PWM technology with greater efficiency at lower cost with dynamic stability
* Wide input voltage range
* Selector switch for inverter & UPS
* Battery high protection
* Over temperature protection
* Reverse phase protection as well as the display
* More backup being a Sine wave inverter (ASIC Control)
* Surge load capacity up to 300%
* Reverse battery protection as well as the display
* Battery fuse blown display
* No humming noise (silent inverter)
* Inverter to mains change over at zero crossing as well as phase synchronization
* 600 VA 12 V DC
* 800 VA 12 V DC
* 1400 VA 24 V DC
Features :
* DSP based design with absolute and stable Sine wave output voltage and frequency
* State of art MOSFET based PWM technology with greater efficiency at lower cost with dynamic stability
* Wide input voltage range
* Selector switch for inverter & UPS
* Battery high protection
* Over temperature protection
* Reverse phase protection as well as the display
* More backup being a Sine wave inverter (ASIC Control)
* Surge load capacity up to 300%
* Reverse battery protection as well as the display
* Battery fuse blown display
* No humming noise (silent inverter)
* Inverter to mains change over at zero crossing as well as phase synchronization
Applications
* Corporate houses
* Call centers
* PLC's
* Browsing centers
* Emergency power systems
* A.C and all compressor based applications
* Petrol filing machine
Our range of UPS finds application in:
*Power back up for House hold
*Domestic computer and its peripheral
*Emergency power systems
*Photography
*Small water pumps and all motor based small applications
*Small drills
*T.V sets, fans and tube-lights, A.C.
* Corporate houses
* Call centers
* PLC's
* Browsing centers
* Emergency power systems
* A.C and all compressor based applications
* Petrol filing machine
Our range of UPS finds application in:
*Power back up for House hold
*Domestic computer and its peripheral
*Emergency power systems
*Photography
*Small water pumps and all motor based small applications
*Small drills
*T.V sets, fans and tube-lights, A.C.
Technical Specification
| Output mode | |
| Output Power | 800VA / 600VA / 1400VA |
| Output Voltage at no load | 220V±7 V |
| Output Frequency | 50.0 Hz ± 0.5Hz |
| Output wave form | |
| Sine-wave battery voltage | 12V / 24V |
| Low battery cut-off | 10.4 ± 0.2 V / 20.0 ± 0.2V |
| Change over time inverter to mains | Approx. 20 m/sec |
| Change over time mains to inverter | Approx. 30 m/sec |
| Input voltage range | 100V to 290V± 5V / 100V to 290V± 5V |
| Mains mode charger current | 10.0 A ± 1A / 10.0 A ± 1A |
| Boost charging voltage | 14.4 V ± 0.2V / 28.8 V ± 0.2V |
| Trigger charging voltage | 13.6V ± 0.2V / 27.2V ± 0.2V |
| Charging power factor | 0.85* |
| Charging Technique | |
| Battery level auto sense smart charger | UPS Mode |
| Change over time inverter to mains | <=8msec / <=8msec |
| Change over time mains to inverter | <=8msec / <=8msec |
| Input voltage range | 180V To 260V ± 5V / 180V To 260V ± 5V |
| Display | L.E.D, Protections, Thermal shutdown, Battery high cut, Battery low cut, Short circuit & overload,Reverse phase |
